Model
No. |
EDP
No. |
Holding
Capacity |
Clamping
Force
at 80 PSIG |
Piston
Diameter |
Opening |
Port
Size |
Weight |
| 8820-2 |
58820 |
663lbs. |
110
lbs. |
20 |
120o |
M5 |
0.88lbs. |
| 8825-1 |
58825 |
663lbs. |
221
lbs. |
25 |
120o |
M5 |
1.00lbs. |
| Model
No. |
A |
A1 |
B |
B1 |
C |
C1 |
D |
D1 |
D2 |
D3 |
E |
E1 |
E2 |
G |
| 8820-2 |
O9 |
M5 |
50 |
35 |
152 |
70 |
25 |
5 |
15 |
5 |
39 |
9 |
3.1 |
8 |
| 8825-1 |
O9 |
M5 |
50 |
35 |
152 |
70 |
25 |
5 |
15 |
5.5 |
39 |
9 |
3.1 |
12 |
Model
No. |
H |
J |
J1 |
J2 |
M |
P |
Q |
Q1 |
R |
R1 |
T |
U |
U1 |
U2 |
| 8820-2 |
13 |
34 |
4.5 |
M6 |
40 |
30.5 |
20.2 |
5 |
55.5 |
2.5.1 |
20.1 |
28 |
34.1 |
4 |
| 8825-1 |
13 |
34 |
6.4 |
M6 |
40 |
40.5 |
20.2 |
5 |
65.5 |
2.5.1 |
20.1 |
30 |
34.1 |
0 |
NOTE:
Maximum air inlet pressure 116 psig.
