TOGGLE CLAMPS

DE-STA-CO(tm) Toggle Clamps

  • HEAVY-DUTY HOLD-DOWN PRODUCTION CLAMPS



Opens a full 210 degrees to completely clear the work area
The combination of mounting flexibility and full opening capacity make these clamps extremely versatile for heavy-duty holding jobs such as auto body fixtures and similar applications.

Model Code & Ordering Information
Model
No.
Base
Option
Hold-Open
Options
Pre-Load
Options
Pipe-Handle
Option
501
503
505
506
508
B=

FB=

LB=
Pivot Base. Permits bolting the clamp linkage to the base accessory and welding it in a position to suit the application.
Base with two dowel holes and one screw hole. Can be added to selected models and welded into set positions.
Long Base. Permits tongue-mounting the linkage to a tang and bolting it in place.
LSC=Spring Clip and Urethane Bumper Assembly. Holds the clamp open under spring tension only.
POL=Positive Open Latch. Prevents accidental clamp closing before workpiece is in position.
R=Toggle-Lock Plus locking release lever.
Can positively maintain the open and closed position of the clamp.
PL=Pre-load Nut and Set Screw. Can maintain the arm in a registered closed position. The clamp locks against itself to avoid accidental opening in applications where no load is placed on the clamp arm.

H=
Pipe Handle. Not Welded.
